Cast Grinding Balls

We offer a variety of Casting Steel Balls Grinding Balls for Mills based on customer requirements, including high, medium, and low chromium content cast steel balls. High chromium balls offer excellent wear resistance, suitable for high-intensity environments; medium chromium balls provide a balance of wear resistance and cost-effectiveness; low chromium balls are ideal for lighter wear and higher impact situations. Customized production meets the needs of different operating conditions.

Contact Now E-Mail Telephone WhatsApp

Product Details

Introduction of the product

We offer a wide selection of Casting Steel Balls for Mills, available in high, medium, and low chromium content based on customer needs. High chromium balls are highly resistant to wear, ideal for harsh conditions. Medium chromium balls strike a balance between durability and cost-effectiveness. Low chromium balls are designed for environments with lower wear but higher impact. We also provide custom manufacturing to suit specific operational requirements. Casting Steel Balls Grinding Ball for Mill

Application in grinding machines and areas

Machines	Industries
·Ball mills	·Mining industry
·SAG mills	·Power stations
·Tower mills	·Cement industry
·Coal grinding machine	·Steel Industry
·Bearing	·Chemical Industry
	·Metallurgical industry

Technical data

Chemical Composition (%)
Name		C	Si	Mn	Cr	Mo	S	P	Cu	Ni
High Chromium Alloy Cast Balls	ZQCr26	2.0-3.3	≤1.2	0.3-1.5	23.0-30.0	0-3.0	≤0.06	≤0.10	0-1.2	0-1.5
	ZQCr20	2.0-3.3	≤1.2	0.3-1.5	18.0-23.0	0-3.0	≤0.06	≤0.10	0-1.2	0-1.5
	ZQCr15	2.0-3.3	≤1.2	0.3-1.5	14.0-18.0	0-3.0	≤0.06	≤0.10	0-1.2	0-1.5
	ZQCr12	2.0-3.3	≤1.2	0.3-1.5	10.0-14.0	0-3.0	≤0.06	≤0.10	0-1.2	0-1.5
Middle Chromium Alloy Cast Balls	ZQCr8	2.1-3.3	≤2.2	0.3-1.5	7.0-10.0	0-1.0	≤0.06	≤0.10	0-0.8	-
Middle Chromium Alloy Cast Balls	ZQCr5	2.1-3.3	≤1.5	0.3-1.5	4.0-6.0	0-1.0	≤0.10	≤0.10	0-0.8	-
Low Chromium Alloy Cast Balls	ZQCr2	2.1-3.6	≤1.5	0.3-1.5	1.0-3.0	0-1.0	≤0.10	≤0.10	0-0.8	-
Bainite Alloy Cast Balls	ZQQTB	3.2-3.8	2.0-3.5	2.0-3.0	-	-	≤0.03	≤0.10	-	-
Bainite Alloy Cast Balls	ZQQTM	3.2-3.8	2.0-3.5	0.5-1.5	-	-	≤0.03	≤0.10	-	-

Physical Features
Name		Surface Hardness (HRC)	Impact Value (J/cm²)	Breakage Rate (%)	Diameter Tolerance (mm)	Diameter (mm)	Drop Test (Times)
High Chromium Alloy Cast Balls	ZQCr26	≥58	≥4J	≤1.0	Φ≤30 +1.0 -1.0 30＜Φ≤60 ＋1.5 -1.0 60＜Φ≤80 +2.0 -1.0 80＜Φ≤100 +2.5 -1.0 Φ＞100 +3.0 -1.0	10-160	＞15000
	ZQCr20	≥58	≥4J	≤1.0
	ZQCr15	≥58	≥4J	≤1.0
	ZQCr12	≥58	≥4J	≤1.0
Middle Chromium Alloy Cast Balls	ZQCr8	≥48	≥4J	≤1.0
Middle Chromium Alloy Cast Balls	ZQCr5	≥47	≥4J	≤1.0
Low Chromium Alloy Cast Balls	ZQCr2	≥45	≥4J	≤1.0
Bainite Alloy Cast Balls	ZQQTB	≥50	≥4J	≤1.0
Bainite Alloy Cast Balls	ZQQTM	≥52	≥4J	≤1.0

Quality Control Technology and Equipment

Plants and Production Equipment

Plants and Production Equipment

Exhibitions

Exhibitions

Why choose us

With these different chromium content cast steel balls, your company can provide tailored solutions based on varying customer needs, ensuring optimal product performance while helping customers maximize cost efficiency.
