Cast Grinding Cylpebs

Cast Grinding Cylpebs are specifically designed to offer enhanced grinding efficiency. Their unique cylindrical shape allows for better contact with the material during the grinding process, ensuring a more efficient breakdown of materials compared to traditional spherical grinding balls. The design helps to reduce the energy consumption of grinding mills while maintaining consistent performance. In industries like mining, cement, and metallurgy, Cast Grinding Cylpebs provide a more controlled grinding action, improving throughput and minimizing operational costs.

Contact Now E-Mail Telephone WhatsApp

Product Details

Introduction of the product

Made from high-quality alloy materials, Cast Grinding Cylpebs are engineered to offer superior wear resistance, making them ideal for high-demand grinding applications. The alloy composition provides excellent hardness and resistance to abrasive forces, which allows them to maintain their shape and performance over extended use. Cast Grinding Cylpebs are particularly effective in situations where high abrasion and impact are present, making them a reliable choice for industries such as mining and cement, where longevity and consistent performance are crucial.

Cast Grinding Cylpebs

Application in grinding machines and areas

Machines	Industries
·Ball mills	·Mining industry
·SAG mills	·Power stations
·Tower mills	·Cement industry
·Coal grinding machine	·Steel Industry
·Bearing	·Chemical Industry
	·Metallurgical industry

Technical data

Chemical Composition (%)
Name		C	Si	Mn	Cr	Mo	S	P	Cu	Ni
High Chromium Alloy Cylpebs	ZQCr26	2.0-3.3	≤1.2	0.3-1.5	23.0-30.0	0-3.0	≤0.06	≤0.10	0-1.2	0-1.5
	ZQCr20	2.0-3.3	≤1.2	0.3-1.5	18.0-23.0	0-3.0	≤0.06	≤0.10	0-1.2	0-1.5
	ZQCr15	2.0-3.3	≤1.2	0.3-1.5	14.0-18.0	0-3.0	≤0.06	≤0.10	0-1.2	0-1.5
	ZQCr12	2.0-3.3	≤1.2	0.3-1.5	10.0-14.0	0-3.0	≤0.06	≤0.10	0-1.2	0-1.5
Middle Chromium Alloy Cast Cylpebs	ZQCr8	2.1-3.3	≤2.2	0.3-1.5	7.0-10.0	0-1.0	≤0.06	≤0.10	0-0.8	-
Middle Chromium Alloy Cast Cylpebs	ZQCr5	2.1-3.3	≤1.5	0.3-1.5	4.0-6.0	0-1.0	≤0.10	≤0.10	0-0.8	-
Low Chromium Alloy Cylpebs	ZQCr2	2.1-3.6	≤1.5	0.3-1.5	1.0-3.0	0-1.0	≤0.10	≤0.10	0-0.8	-
Bainite Alloy Cast Cylpebs	ZQQTB	3.2-3.8	2.0-3.5	2.0-3.0	-	-	≤0.03	≤0.10	-	-
Bainite Alloy Cast Cylpebs	ZQQTM	3.2-3.8	2.0-3.5	0.5-1.5	-	-	≤0.03	≤0.10	-	-

Chemical Composition (%)
Name		C	Si	Mn	Cr	Mo	S	P	Cu	Ni
High Chromium Alloy Cylpebs	ZQCr26	2.0-3.3	≤1.2	0.3-1.5	23.0-30.0	0-3.0	≤0.06	≤0.10	0-1.2	0-1.5
	ZQCr20	2.0-3.3	≤1.2	0.3-1.5	18.0-23.0	0-3.0	≤0.06	≤0.10	0-1.2	0-1.5
	ZQCr15	2.0-3.3	≤1.2	0.3-1.5	14.0-18.0	0-3.0	≤0.06	≤0.10	0-1.2	0-1.5
	ZQCr12	2.0-3.3	≤1.2	0.3-1.5	10.0-14.0	0-3.0	≤0.06	≤0.10	0-1.2	0-1.5
Middle Chromium Alloy Cylpebs	ZQCr8	2.1-3.3	≤2.2	0.3-1.5	7.0-10.0	0-1.0	≤0.06	≤0.10	0-0.8	-
Middle Chromium Alloy Cylpebs	ZQCr5	2.1-3.3	≤1.5	0.3-1.5	4.0-6.0	0-1.0	≤0.10	≤0.10	0-0.8	-
Low Chromium Alloy Cylpebs	ZQCr2	2.1-3.6	≤1.5	0.3-1.5	1.0-3.0	0-1.0	≤0.10	≤0.10	0-0.8	-
Bainite Alloy Cylpebs	ZQQTB	3.2-3.8	2.0-3.5	2.0-3.0	-	-	≤0.03	≤0.10	-	-
Bainite Alloy Cylpebs	ZQQTM	3.2-3.8	2.0-3.5	0.5-1.5	-	-	≤0.03	≤0.10	-	-

Quality Control Technology and Equipment

Plants and Production Equipment

Plants and Production Equipment

Exhibitions

Exhibitions

Why choose us

One of the main advantages of Cast Grinding Cylpebs is their versatility and customization options. These grinding media can be manufactured in a wide range of sizes and materials to meet the specific needs of different industries and applications. Whether for fine grinding or coarse grinding, Cast Grinding Cylpebs can be customized to provide the optimal balance of performance and durability for any grinding operation. Their adaptability makes them suitable for a variety of industries, including mining, cement, and chemical processing, ensuring optimal grinding results in all conditions.
