Hot Rolled/ Forged Grinding Ball For Copper Gold Iron Silver

The Hot Rolled/Forged Grinding Ball for Copper, Gold, Iron, Silver is made from premium steel, engineered to withstand the harsh and demanding conditions encountered in grinding precious and base metals. The advanced hot rolling and forging processes result in a product with exceptional hardness and toughness, making it highly resistant to breakage and wear. Whether used in grinding copper, gold, iron, or silver ores, these grinding balls maintain their integrity even under the intense impacts and abrasive forces typical in mineral processing. This durability extends the service life of the grinding balls, minimizing downtime and replacement costs, and ensuring consistent performance throughout long operating periods.

Contact Now E-Mail Telephone WhatsApp

Product Details

Introduction of the product

The Hot Rolled/Forged Grinding Ball for Copper, Gold, Iron, Silver is specifically designed to enhance grinding efficiency and optimize metal recovery in milling operations. These balls provide excellent energy transfer during the grinding process, improving material breakdown and ensuring better throughput. The uniformity of the ball size and hardness helps to minimize friction and reduce energy consumption, contributing to smoother operations. By improving the efficiency of grinding processes, these balls help maximize the recovery rates of valuable metals like copper, gold, iron, and silver, leading to higher yields and improved cost-effectiveness for mining and metallurgical industries.

Application in grinding machines and areas

Machines	Industries
·Ball mills	·Mining industry
·SAG mills	·Power stations
·Tower mills	·Cement industry
·Coal grinding machine	·Steel Industry
·Bearing	·Chemical Industry
	·Metallurgical industry

Technical data

Chemical Composition (%)
Steel Specification	C	Mn	Si	Cr	S	P
40Cr	0.37-0.44	0.50-0.80	0.17-0.37	0.80-1.15	≤0.035	≤0.035
42CrMo	0.38-0.45	0.50-0.80	0.17-0.37	0.90-1.25	≤0.035	≤0.035
60Mn	0.57-0.65	0.70-1.00	0.17-0.37	≤0.25	≤0.035	≤0.035
65Mn	0.62-0.72	0.90-1.20	0.17-0.37	≤0.25	≤0.035	≤0.035
#45/C45	0.42-0.54	0.50-0.80	0.17-0.37	≤0.15	≤0.035	≤0.035
ZT-10	0.60-0.78	0.65-1.33	0.25-0.65	≤0.45	≤0.035	≤0.035
B2	0.70-0.92	0.70-1.00	0.17-0.37	0.40-0.70	≤0.035	≤0.035
B3	0.52-0.65	0.66-1.00	1.30-1.90	0.74-1.20	≤0.030	≤0.030
B4	0.65-0.75	0.50-0.70	1.20-1.40	0.85-1.00	≤0.025	≤0.025
B6	0.75-0.90	0.80-1.02	0.17-0.37	0.88-0.98	≤0.035	≤0.035
BU	0.95-1.05	0.95-1.05	0.15-0.35	0.45-0.55	≤0.035	≤0.035
BL	0.55-0.75	0.65-0.85	0.15-0.35	0.70-1.20	≤0.035	≤0.035
BG	0.90-1.05	0.35-0.95	0.15-0.35	1.00-1.70	≤0.035	≤0.035

Physical Features
Diameter (mm) (inches)	Surface Hardness (HRC)	Diameter Tolerance (mm)	Impact Value (J/cm²)	Breakage Rate (%)	Drop Test (times)
20 (0.79)	>60	+2.0 -1.0	≥12	≤1	>15000
25 (0.98)
30 (1.18)
40 (1.57)
50 (1.97)
60 (2.36)		+3.0 -1.5
65(5.56)
70 (2.76)
75 (3.00)
80 (3.15)
90 (3.54)
100 (3.94)		+4.0 -2.0
120 (4.72)	>58
125 (4.92)
140 (5.51)	>55	+5.0 -3.0
150 (5.91)

Quality Control Technology and Equipment

Plants and Production Equipment

Plants and Production Equipment

Exhibitions

Exhibitions

Why choose us

The Hot Rolled/Forged Grinding Ball for Copper, Gold, Iron, Silver can be customized to suit the unique requirements of different milling environments. Available in various sizes, hardness levels, and steel grades, these grinding balls can be tailored for specific applications depending on the type of ore being processed and the milling conditions. Whether for coarse grinding or fine material reduction, these grinding balls can be adapted to meet the needs of different operations, ensuring optimal performance. Customization ensures that companies can achieve the best balance of wear resistance, efficiency, and cost-effectiveness for processing copper, gold, iron, and silver ores.
